Setanaxib (GKT137831)

Catalog No.S7171

Setanaxib (GKT137831) Chemical Structure

Molecular Weight(MW): 394.85

GKT137831 is a potent, dual NADPH oxidase NOX1/NOX4 inhibitor with Ki of 110 nM and 140 nM, respectivelyl; ~10-fold selectivity towards NOX1, 4 and 5 over NOX2, does not inhibit XO or scavange ROS/RNS.

Size Price Stock Quantity
USD 147 In stock
USD 477 In stock
USD 997 In stock
Bulk Discount

Free Overnight Delivery on orders over $ 500
Next day delivery by 10:00 a.m. Order now.

Cited by 18 Publications

4 Customer Reviews

  • (C) Indicated macrophages were treated with LPS (100 ng/mL) in the absence or presence of GKT137831 (1 μmol/L) for 24 h. PKM2 mRNA and lactate levels were assayed (n = 3, *, p < 0.05 versus LPS group).

    Mol Med, 2016, doi: 10.2119/molmed.2015.00250. Setanaxib (GKT137831) purchased from Selleck.

  • Serum markers of liver injury and liver pathology in mice fed control (Ctrl) or ethanol (EtOH) for four weeks with or without GKT137831 for the last two weeks. (A) Light microscopy with hematoxylin & eosin staining shows accumulation of lipid droplets (arrows) and necrosis (arrowheads) in the liver of ethanol-fed mice, which was attenuated by GKT137831 treatment. (B) Serum alanine aminotransferase (ALT) and aspartate aminotransferase (AST) activities. Serum ALT and AST activities were measured by using Infinity ALT and AST Reagents. Scale bar: 20μM. Results are mean ± SD (n=6). Results for bars that do not share a letter differed significantly among groups (P <0.05). Significant differences among groups are determined by ANOVA followed by Tukey’s test.

    Biochim Biophys Acta, 2016, 1861(1 Pt A):2912-2921. . Setanaxib (GKT137831) purchased from Selleck.

  • A549 cells were treated with GKT137831 (20 µM) or NAC (25 µM) after transfection with NOX4 plasmid for 48 h. Nrf2 expression was analyzed by western blotting (B). NOX4-overexpressed A549 cells were pretreated with MG132 (25 µM) after the addition of NAC or GKT137831 (C).

    Exp Cell Res, 2017, 352(2):245-254. Setanaxib (GKT137831) purchased from Selleck.

  • AGE3-BSA-induced apoptosis in A7r5 cells was mediated by NAD(P)H oxidase. (a) Cultured A7r5 cells were incubated in calcification medium containing cBSA, or AGE3-BSA (100 µg/mL) in the presence or absence of NAD(P)H oxidase inhibitors including GKT137831 (20 µM) or VAS2870 (10 µM) for three days. Apoptosis was evaluated by TUNEL assay, as described in the Method section. Cells in the culture were identified by nuclear staining with Hoechst, and evaluated under a fluorescence microscope; (b) For quantification, Hoechst and TUNEL double positive cells were counted in 10 random microscopic fields at 200× magnification, and expressed as percent TUNEL positive cells in a culture. Statistical significance of the results was analyzed by one-way ANOVA followed by LDS post-hoc test. Statistical significance was denoted as follows, ** p < 0.001 vs. AGE3-BSA.

    Int J Mol Sci, 2016, 17(9). pii: E1567. Setanaxib (GKT137831) purchased from Selleck.

Purity & Quality Control

Choose Selective NADPH-oxidase Inhibitors

Biological Activity

Description GKT137831 is a potent, dual NADPH oxidase NOX1/NOX4 inhibitor with Ki of 110 nM and 140 nM, respectivelyl; ~10-fold selectivity towards NOX1, 4 and 5 over NOX2, does not inhibit XO or scavange ROS/RNS.
NOX1 [1]
(Cell-based assay)
NOX4 [1]
(Cell-based assay)
110 nM(Ki) 140 nM(Ki)
In vitro

GKT137831 attenuates hypoxia-induced H(2)O(2) release, cell proliferation, and TGF-β1 expression and blunted reductions in PPARγ in HPAECs and HPASMCs. [2] GKT137831 also prevents oxidative stress in response to hyperglycemia in human aortic endothelial cells. [3]

Cell Data
Cell Lines Assay Type Concentration Incubation Time Formulation Activity Description PMID
HPAECs MnPhVJJwdGmoZYLheIlwdiCjc4PhfS=> Mkj6NE4yNTJyIN88US=> NFHiXmozPCCq NYTpN|F6dm9ic3nncolncWOjboSg[YZn\WO2IH;uJJBzd2yrZnXyZZRqd25? NUHqc2x{OjJ7MESxPVg>
HPASMCs MVnQdo9tcW[ncnH0bY9vKGG|c3H5 MXGwMlEuOjBizszN NWHSUWpXOjRiaB?= NHL0dllifHSnboXheIVlKGOnbHygdJJwdGmoZYLheIlwdg>? MoD3NlI6ODRzOUi=

... Click to View More Cell Line Experimental Data

In vivo In WT and SOD1mut mice, GKT137831 (60 mg/kg i.g.) blocks liver fibrosis and downregulates markers of oxidative stress, inflammation, and fibrosis. [1] GKT137831 (60 mg/kg/d p.o.) also attenuates chronic hypoxia–induced right ventricular hypertrophy, vascular remodeling, lung cell proliferation, and hypoxic alterations in lung PPARγ and TGF-β1 expression in mouse model of chronic hypoxia exposure. [2] In diabetic apolipoprotein E-deficient mice, GKT137831 (60 mg/kg/d p.o.) attenuates diabetes mellitus-accelerated atherosclerosis. [3] Moreover, in angII-infused c-hNox4Tg mice, GKT137831 abolishes the increase in oxidative stress, suppresses Akt-mTOR and NF-κB signaling pathway and attenuates cardiac remodeling. [4]


Cell Research:


- Collapse
  • Cell lines: Hypoxic HPASMC and HPAECs
  • Concentrations: 20 μM
  • Incubation Time: 72 hours
  • Method:

    Hypoxic HPASMC and HPAEC proliferation is determined using MTT assay, by Western blotting to detect proliferating cell nuclear antigen (PCNA) expression, or by manual cell counting after Trypan blue staining. Amplex Red Hydrogen Peroxide/Peroxidase Assay Kit is used to measure H2O2 released into the culture media from HPAECs or HPASMCs. After exposure to control or hypoxic environments for 72 hours, Amplex Red reagent is added, and the cells are returned to control or hypoxic environments for an additional hour before fluorescence measurements.

    (Only for Reference)
Animal Research:


- Collapse
  • Animal Models: Mouse models of liver fibrosis
  • Formulation: corn oil
  • Dosages: 60 mg/kg daily
  • Administration: i.g.
    (Only for Reference)

Solubility (25°C)

In vitro DMSO 78 mg/mL warmed (197.54 mM)
Water Insoluble
Ethanol Insoluble
In vivo Add solvents to the product individually and in order(Data is from Selleck tests instead of citations):
2% DMSO+2% Tween 80+30% PEG 300+ddH2O
For best results, use promptly after mixing.

* Please note that Selleck tests the solubility of all compounds in-house, and the actual solubility may differ slightly from published values. This is normal and is due to slight batch-to-batch variations.

Chemical Information

Molecular Weight 394.85


CAS No. 1218942-37-0
Storage powder
in solvent
Synonyms N/A

Bio Calculators

Molarity Calculator

Molarity Calculator

Calculate the mass, volume or concentration required for a solution. The Selleck molarity calculator is based on the following equation:

Mass (mg) = Concentration (mM) × Volume (mL) × Molecular Weight (g/mol)

  • Mass
    Molecular Weight

*When preparing stock solutions, please always use the batch-specific molecular weight of the product found on the via label and MSDS / COA (available on product pages).

Dilution Calculator

Dilution Calculator

Calculate the dilution required to prepare a stock solution. The Selleck dilution calculator is based on the following equation:

Concentration (start) x Volume (start) = Concentration (final) x Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2 ( Input Output )

  • C1

* When preparing stock solutions always use the batch-specific molecular weight of the product found on the vial label and MSDS / COA (available online).

The Serial Dilution Calculator Equation

  • Serial Dilutions

  • Computed Result

  • C1=C0/X C1: LOG(C1):
    C2=C1/X C2: LOG(C2):
    C3=C2/X C3: LOG(C3):
    C4=C3/X C4: LOG(C4):
    C5=C4/X C5: LOG(C5):
    C6=C5/X C6: LOG(C6):
    C7=C6/X C7: LOG(C7):
    C8=C7/X C8: LOG(C8):
Molecular Weight Calculator

Molecular Weight Calculator

Enter the chemical formula of a compound to calculate its molar mass and elemental composition:

Total Molecular Weight: g/mol

Tip: Chemical formula is case sensitive. C10H16N2O2 c10h16n2o2

Instructions to calculate molar mass (molecular weight) of a chemical compound:

To calculate molar mass of a chemical compound, please enter its chemical formula and click 'Calculate'.

Definitions of molecular mass, molecular weight, molar mass and molar weight:

Molecular mass (molecular weight) is the mass of one molecule of a substance and is expressed in the unified atomic mass units (u). (1 u is equal to 1/12 the mass of one atom of carbon-12)
Molar mass (molar weight) is the mass of one mole of a substance and is expressed in g/mol.

Molarity Calculator

Mass Concentration Volume Molecular Weight
