Phospho-JNK1/ JNK2/ JNK3 (Tyr 185/ Tyr 185/ Tyr 223) Rabbit mAb

Catalog No.: F1573

Lane 1: HEK-293
Lane 2: HEK-293 (UV-C, 200J/m2, recovery for 30 min)
Lane 3: NIH/3T3
Lane 4: NIH/3T3 (UV-C, 200J/m2, recovery for 1h)

2 Customer Reviews

Experiment Essentials

Subcellular Location: Cytoplasm, Nucleus, Cell junction, Synapse.
WB
Recommending using RIPA/NP-40 Lysis Buffer to prepare lysates.
Recommended primary antibody dilution ratio 1:5000.

Usage Information

Dilution
WB1:5000 IP1:70

Application
WB, IP

Source
Rabbit

Reactivity
Human, Mouse, Rat

Storage Buffer
PBS, pH 7.2+50% Glycerol+0.05% BSA+0.01% NaN₃

Storage (from the date of receipt)
–20°C (avoid freeze-thaw cycles), 2 years

Predicted MW
48 kDa

Positive Control	HEK-293 (20J/m2 UV-C treated, recovery for 30 min); NIH/3T3 (20J/m2 UV-C treated, recovery for 1 h); C6s ((20J/m2 UV-C treated, recovery for 30 min); HeLas (20J/m2 UV-C treated, recovery for 1 h)
Negative Control	HEK-293; NIH/3T3; C6; HeLa

Exprimental Methods

WB
Experimental Protocol: Sample preparation 1. Tissue: Lyse the tissue sample by adding an appropriate volume of ice-cold RIPA/NP-40 Lysis Buffer (containing Protease Inhibitor Cocktail, Phosphatase Inhibitor Cocktail)，and homogenize the tissue at a low temperature or lyse it by sonication on ice, then incubate on ice for 30 minutes. 2. Adherent cell: Aspirate the culture medium and transfer the cells into an EP tube. Wash the cells with ice-cold PBS twice. Add an appropriate volume of RIPA/NP-40 Lysis Buffer (containing Protease Inhibitor Cocktail, Phosphatase Inhibitor Cocktail), sonicate to lyse the cells, and incubate on ice for 30 minutes. 3. Suspension cell: Transfer the culture medium to a pre-cooled centrifuge tube. Centrifuge and aspirate the supernatant. Wash the cells with ice-cold PBS twice.Add an appropriate volume of RIPA/NP-40 Lysis Buffer (containing Protease Inhibitor Cocktail, Phosphatase Inhibitor Cocktail), sonicate to lyse the cells, and incubate on ice for 30 minutes. 4. Place the lysate into a pre-cooled microcentrifuge tube. Centrifuge at 4°C for 15 min. Collect the supernatant; 5. Remove a small volume of lysate to determine the protein concentration; 6. Combine the lysate with protein loading buffer. Boil 20 µL sample under 95-100°C for 5 min. Centrifuge for 5 min after cool down on ice. Electrophoretic separation 1. According to the concentration of extracted protein, load appropriate amount of protein sample and marker onto SDS-PAGE gels for electrophoresis. Recommended separating gel (lower gel) concentration: 10%. Reference Table for Selecting SDS-PAGE Separation Gel Concentrations 2. Power up 80V for 30 minutes. Then the power supply is adjusted (110 V~150 V), the Marker is observed, and the electrophoresis can be stopped when the indicator band of the predyed protein Marker where the protein is located is properly separated. (Note that the current should not be too large when electrophoresis, too large current (more than 150 mA) will cause the temperature to rise, affecting the result of running glue. If high currents cannot be avoided, an ice bath can be used to cool the bath.) Transfer membrane 1. Take out the converter, soak the clip and consumables in the pre-cooled converter; 2. Activate PVDF membrane with methanol for 1 min and rinse with transfer buffer; 3. Install it in the order of "black edge of clip - sponge - filter paper - filter paper - glue -PVDF membrane - filter paper - filter paper - sponge - white edge of clip"; 4. The protein was electrotransferred to PVDF membrane. ( 0.45 µm PVDF membrane is recommended ) Reference Table for Selecting PVDF Membrane Pore Size Specifications Recommended conditions for wet transfer: 200 mA, 120 min. ( Note that the transfer conditions can be adjusted according to the protein size. For high-molecular-weight proteins, a higher current and longer transfer time are recommended. However, ensure that the transfer tank remains at a low temperature to prevent gel melting.) Block 1. After electrotransfer, wash the film with TBST at room temperature for 5 minutes; 2. Incubate the film in the blocking solution ( recommending 5% BSA solution) for 1 hour at room temperature; 3. Wash the film with TBST for 3 times, 5 minutes each time. Antibody incubation 1. Use 5% skim milk powder to prepare the primary antibody working liquid (recommended dilution ratio for primary antibody 1:5000), gently shake and incubate with the film at 4°C overnight; 2. Wash the film with TBST 3 times, 5 minutes each time; 3. Add the secondary antibody to the blocking solution and incubate with the film gently at room temperature for 1 hour; 4. After incubation, wash the film with TBST 3 times for 5 minutes each time. Antibody staining 722. Add the prepared ECL luminescent substrate (or select other color developing substrate according to the second antibody) and mix evenly; 2. Incubate with the film for 1 minute, remove excess substrate (keep the film moist), wrap with plastic film, and expose in the imaging system.

Experimental Protocol:

Sample preparation

1. Tissue: Lyse the tissue sample by adding an appropriate volume of ice-cold RIPA/NP-40 Lysis Buffer (containing Protease Inhibitor Cocktail, Phosphatase Inhibitor Cocktail)，and homogenize the tissue at a low temperature or lyse it by sonication on ice, then incubate on ice for 30 minutes.

2. Adherent cell: Aspirate the culture medium and transfer the cells into an EP tube. Wash the cells with ice-cold PBS twice. Add an appropriate volume of RIPA/NP-40 Lysis Buffer (containing Protease Inhibitor Cocktail, Phosphatase Inhibitor Cocktail), sonicate to lyse the cells, and incubate on ice for 30 minutes.

3. Suspension cell: Transfer the culture medium to a pre-cooled centrifuge tube. Centrifuge and aspirate the supernatant. Wash the cells with ice-cold PBS twice.Add an appropriate volume of RIPA/NP-40 Lysis Buffer (containing Protease Inhibitor Cocktail, Phosphatase Inhibitor Cocktail), sonicate to lyse the cells, and incubate on ice for 30 minutes.

4. Place the lysate into a pre-cooled microcentrifuge tube. Centrifuge at 4°C for 15 min. Collect the supernatant;

5. Remove a small volume of lysate to determine the protein concentration;

6. Combine the lysate with protein loading buffer. Boil 20 µL sample under 95-100°C for 5 min. Centrifuge for 5 min after cool down on ice.

Electrophoretic separation

1. According to the concentration of extracted protein, load appropriate amount of protein sample and marker onto SDS-PAGE gels for electrophoresis. Recommended separating gel (lower gel) concentration: 10%. Reference Table for Selecting SDS-PAGE Separation Gel Concentrations

2. Power up 80V for 30 minutes. Then the power supply is adjusted (110 V~150 V), the Marker is observed, and the electrophoresis can be stopped when the indicator band of the predyed protein Marker where the protein is located is properly separated. (Note that the current should not be too large when electrophoresis, too large current (more than 150 mA) will cause the temperature to rise, affecting the result of running glue. If high currents cannot be avoided, an ice bath can be used to cool the bath.)

Transfer membrane

1. Take out the converter, soak the clip and consumables in the pre-cooled converter;

2. Activate PVDF membrane with methanol for 1 min and rinse with transfer buffer;

3. Install it in the order of "black edge of clip - sponge - filter paper - filter paper - glue -PVDF membrane - filter paper - filter paper - sponge - white edge of clip";

4. The protein was electrotransferred to PVDF membrane. ( 0.45 µm PVDF membrane is recommended ) Reference Table for Selecting PVDF Membrane Pore Size Specifications

Recommended conditions for wet transfer: 200 mA, 120 min.

( Note that the transfer conditions can be adjusted according to the protein size. For high-molecular-weight proteins, a higher current and longer transfer time are recommended. However, ensure that the transfer tank remains at a low temperature to prevent gel melting.)

Block

1. After electrotransfer, wash the film with TBST at room temperature for 5 minutes;

2. Incubate the film in the blocking solution ( recommending 5% BSA solution) for 1 hour at room temperature;

3. Wash the film with TBST for 3 times, 5 minutes each time.

Antibody incubation

1. Use 5% skim milk powder to prepare the primary antibody working liquid (recommended dilution ratio for primary antibody 1:5000), gently shake and incubate with the film at 4°C overnight;

2. Wash the film with TBST 3 times, 5 minutes each time;

3. Add the secondary antibody to the blocking solution and incubate with the film gently at room temperature for 1 hour;

4. After incubation, wash the film with TBST 3 times for 5 minutes each time.

Antibody staining

722. Add the prepared ECL luminescent substrate (or select other color developing substrate according to the second antibody) and mix evenly;

2. Incubate with the film for 1 minute, remove excess substrate (keep the film moist), wrap with plastic film, and expose in the imaging system.

Datasheet & SDS

Biological Description

Specificity
Phospho-JNK1/ JNK2/ JNK3 (Tyr 185/ Tyr 185/ Tyr 223) Rabbit mAb recognizes endogenous levels of total JNK1 (pY185) + JNK2 (pY185) + JNK3 (pY223) protein.This antibody does not recognize unphosphorylated JNK1/2/3.

Specificity

Phospho-JNK1/ JNK2/ JNK3 (Tyr 185/ Tyr 185/ Tyr 223) Rabbit mAb recognizes endogenous levels of total JNK1 (pY185) + JNK2 (pY185) + JNK3 (pY223) protein.This antibody does not recognize unphosphorylated JNK1/2/3.

Uniprot ID
P45983

Clone
G4D15

Background
The stress-activated protein kinase/Jun-amino-terminal kinase (SAPK/JNK) is notably and predominantly triggered by a diverse array of environmental stresses and occasionally by growth factors and GPCR agonists. Similar to other MAPKs, its core signaling module consists of a MAPKKK, typically MEKK1-MEKK4, or one of the mixed lineage kinases (MLKs), which activate MKK4/7 through phosphorylation. Upon activation, MKKs further phosphorylate and activate the SAPK/JNK kinase. Stress cues are conveyed to this cascade by small GTPases of the Rho family (Rac, Rho, cdc42), with Rac1 and cdc42 facilitating the stimulation of MEKKs and MLKs. Alternatively, activation of MKK4/7 can occur independently of GTPases through the stimulation of a germinal center kinase (GCK) family member. The SAPK/JNK genes undergo alternative splicing, yielding numerous isoforms. When active as a dimer, SAPK/JNK can translocate to the nucleus and modulate transcription by influencing c-Jun, ATF-2, and various other transcription factors.

Background

The stress-activated protein kinase/Jun-amino-terminal kinase (SAPK/JNK) is notably and predominantly triggered by a diverse array of environmental stresses and occasionally by growth factors and GPCR agonists. Similar to other MAPKs, its core signaling module consists of a MAPKKK, typically MEKK1-MEKK4, or one of the mixed lineage kinases (MLKs), which activate MKK4/7 through phosphorylation. Upon activation, MKKs further phosphorylate and activate the SAPK/JNK kinase. Stress cues are conveyed to this cascade by small GTPases of the Rho family (Rac, Rho, cdc42), with Rac1 and cdc42 facilitating the stimulation of MEKKs and MLKs. Alternatively, activation of MKK4/7 can occur independently of GTPases through the stimulation of a germinal center kinase (GCK) family member. The SAPK/JNK genes undergo alternative splicing, yielding numerous isoforms. When active as a dimer, SAPK/JNK can translocate to the nucleus and modulate transcription by influencing c-Jun, ATF-2, and various other transcription factors.

References
[1] Kyriakis JM, et al. Physiol Rev. 2001 Apr;81(2):807-69. [2] Ichijo H, et al. Oncogene. 1999 Nov 1;18(45):6087-93.

Reference Table for Selecting PVDF Membrane Pore Size Specifications

Protein Size (kDa)	PVDF Transfer Membrane Pore Size (μm)
< 10	0.22
10-20	0.22
20-30	0.45
30-45	0.45
45-70	0.45
80-100	0.45
100-140	0.45
> 140	0.45

Tech Support

Answers to questions you may have can be found in the inhibitor handling instructions. Topics include how to prepare stock solutions, how to store inhibitors, and issues that need special attention for cell-based assays and animal experiments.

Handling Instructions

Tel: +1-832-582-8158 Ext:3
If you have any other enquiries, please leave a message.

* Indicates a Required Field

Protein Size (kDa)	Separating Gel Percentage
4-40	20%
12-45	15%
10-70	12.5%
15-100	10%
25-100	8%
60-210	5%
