Ponatinib (AP24534)

Ponatinib (AP24534) is a novel, potent multi-target inhibitor of Abl, PDGFRα, VEGFR2, FGFR1 and Src with IC50 of 0.37 nM, 1.1 nM, 1.5 nM, 2.2 nM and 5.4 nM in cell-free assays, respectively.

Price Stock Quantity
In DMSO USD 100 In stock
USD 110 In stock
USD 370 In stock
USD 970 In stock
Bulk Inquiry

Massive Discount Available

Free Overnight Delivery on all orders over $ 500.

Ponatinib (AP24534) Chemical Structure

Ponatinib (AP24534) Chemical Structure
Molecular Weight: 532.56

Validation & Quality Control

Customer Product Validation(2)

Quality Control & MSDS

Related Compound Libraries

Bcr-Abl Inhibitors with Unique Features

  • Selective Bcr-Abl Inhibitor

    Nilotinib (AMN-107) Bcr-Abl-selective, IC50<30 nM.

  • Most Potent Bcr-Abl Inhibitor

    GZD824 Bcr-Abl(WT), IC50=0.34 nM; Bcr-Abl(T315I), IC50=0.68 nM.

  • FDA-approved Bcr-Abl Inhibitor

    Dasatinib Approved by FDA for CML and Ph+ ALL.

  • Newest Bcr-Abl Inhibitor

    GZD824 Orally bioavailable Bcr-Abl inhibitor for Bcr-Abl(WT) and Bcr-Abl(T315I) with IC50 of 0.34 nM and 0.68 nM, respectively.

Product Information

  • Compare Bcr-Abl Inhibitors
    Compare Bcr-Abl Products
  • Research Area
  • Ponatinib (AP24534) Mechanism

Product Description

Biological Activity

Description Ponatinib (AP24534) is a novel, potent multi-target inhibitor of Abl, PDGFRα, VEGFR2, FGFR1 and Src with IC50 of 0.37 nM, 1.1 nM, 1.5 nM, 2.2 nM and 5.4 nM in cell-free assays, respectively.
Targets Abl [1]
(Cell-free assay)
PDGFRα [1]
(Cell-free assay)
VEGFR2 [1]
(Cell-free assay)
FGFR1 [1]
(Cell-free assay)

 View  More

IC50 0.37 nM 1.1 nM 1.5 nM 2.2 nM
In vitro AP24534 potently inhibits native Abl, AblT315I, and other clinically important Abl kinase domain mutants with IC50 of 0.30 nM–2 nM. AP24534 doesn't inhibit Aurora kinase family members, nor does it inhibit insulin receptor or CDK2/cyclin E. AP24534 inhibits proliferation of Ba/F3 cells expressing Bcr-Abl with IC50 of 0.5 nM, as well as Ba/F3 cells expressing a range of Bcr-Abl mutants with IC50 of 0.5 nM–36 nM. The inhibition of proliferation by AP24534 is correlated with induction of apoptosis. [1-2] In leukemic cell lines containing activated forms of FLT3, KIT, FGFR1, and PDGFRα receptors, AP24534 potently inhibits receptor phosphorylation and cellular proliferation with IC50 of 0.3 nM to 20 nM. In MV4-11 (FLT3-ITD(+/+)) but not RS4;11 (FLT3-ITD(–/–)) AML cells, AP24534 inhibits FLT3 signaling and induced apoptosis at less than 10 nM. AP24534 inhibits viability of primary leukemic blasts from a FLT3-ITD positive AML patient with IC50 of 4 nM but not those from patients with AML expressing native FLT3. [3] In Ba/F3 cells engineered to express activated FGFR1-4, AP24534 potently inhibits FGFR-mediated signaling and viability with IC50 lower than 40 nM. In cell lines representing multiple tumor types (endometrial, bladder, gastric, breast, lung, and colon), and containing FGFRs dysregulated by a variety of mechanisms, AP24534 inhibits FGFR-mediated signaling with IC50 less than 40 nM and inhibits cell growth with IC50 of 7 nM–181 nM. [4]
In vivo In a mouse xenograft model of Ba/F3 cells expressing native Bcr-Abl, AP24534 (2.5 mg/kg and 5 mg/kg) prolongs mice median survival. In the xenograft model of Ba/F3 Bcr-AblT315I, AP24534 (10 mg/kg–50 mg/kg) significantly suppresses tumor growth. AP24534 (30 mg/kg) decreases the phosphorylated Bcr-Abl and phosphorylated CrkL levels in the tumors. [2]

Protocol(Only for Reference)

Kinase Assay: [1]

Peptide substrate phosphorylation assays with GST-Abl kinase domains The effect of AP24534 (0-320 nM) on GST-Abl kinase activity is assessed by using a synthetic peptide substrate (Abltide: EAIYAAPFAKKK). Assays are carried out at 30 °C for 15 min in 25 μL reaction mixture: 8 mM MOPS (pH 7), 0.2 mM EDTA, 50 μM Abltide, 30 mM MgCl2, 10 mM β-glycerol phosphate, 1 mM EGTA, 0.002% Brij-35, 0.4 mM DTT, 0.2 mg/mL BSA, 0.4 mM sodium orthovanadate, 10 nM WT or mutant GST-Abl kinase, and 100 µM ATP/γ-32[P]ATP (5000 cpm/pmol). Reactions are terminated by transferring a portion of the reaction mixture onto a p81 phosphocellulose filter and immersing in 0.75% phosphoric acid. Filters are washed 3 times in 0.75% phosphoric acid, rinsed in acetone, and air dried; phosphate incorporation is determined by scintillation counting. All results are corrected for background binding to the filters, as determined by omitting peptide substrate from the kinase reaction. Time course experiments to establish the linear range of enzymatic activity precedes kinase assays.

Cell Assay: [2]

Cell lines Ba/F3 cells expressing Bcr-Abl or a range of single mutations in the kinase domain of Bcr-Abl
Concentrations 0-625 nM
Incubation Time 72 hours
Method Ba/F3 cell lines are distributed in 96-well plates (4 × 103 cells/well) and incubated with AP24534 for 72 hours. Proliferation is measured using a methanethiosulfonate (MTS)-based viability assay (CellTiter96 Aqueous One Solution). All values are normalized to the control wells with no drug. IC50 values are reported as the mean of three independent experiments performed in quadruplicat

Animal Study: [1]

Animal Models Mouse xenograft models of Ba/F3 cells expressing Bcr-Abl or Bcr-AblT315I
Formulation Dissolved in 25 mM citrate buffer, pH 2.75
Dosages 2.5 mg/kg and 5 mg/kg for Ba/F3 Bcr-Abl; 2.5 mg/kg–50 mg/kg for Ba/F3 Bcr-AblT315I
Administration Oral gavage once daily

Conversion of different model animals based on BSA (Value based on data from FDA Draft Guidelines)

SpeciesMouseRatRabbitGuinea pigHamsterDog
Weight (kg)
Body Surface Area (m2)0.0070.0250.
Km factor36128520
Animal A (mg/kg) = Animal B (mg/kg) multiplied by  Animal B Km
Animal A Km

For example, to modify the dose of resveratrol used for a mouse (22.4 mg/kg) to a dose based on the BSA for a rat, multiply 22.4 mg/kg by the Km factor for a mouse and then divide by the Km factor for a rat. This calculation results in a rat equivalent dose for resveratrol of 11.2 mg/kg.

Rat dose (mg/kg) = mouse dose (22.4 mg/kg) ×  mouse Km(3)  = 11.2 mg/kg
rat Km(6)


[1] O'Hare T, et al. Cancer Cell, 2009, 16(5), 401-412.

[2] Huang WS, et al. J Med Chem, 2010, 53(12), 4701-4719.

view more

Clinical Trial Information( data from http://clinicaltrials.gov, updated on 2015-09-19)

NCT Number Recruitment Conditions Sponsor
Start Date Phases
NCT01888562 Not yet recruiting Endometrial Neoplasms Washington University School of Medicine August 2015 --
NCT01888562 Not yet recruiting Endometrial Neoplasms Washington University School of Medicine August 2015 --
NCT02478164 Recruiting Glioblastoma Dana-Farber Cancer Institute July 2015 Phase 2
NCT02448095 Not yet recruiting Chronic Myeloid Leukemia|Philadelphia Positive Gruppo Italiano Malattie EMatologiche dellAdulto July 2015 --
NCT02478164 Recruiting Glioblastoma Dana-Farber Cancer Institute July 2015 Phase 2

view more

Chemical Information

Download Ponatinib (AP24534) SDF
Molecular Weight (MW) 532.56


CAS No. 943319-70-8
Storage 3 years -20℃powder
6 months-80℃in solvent
Synonyms N/A
Solubility (25°C) * In vitro DMSO 30 mg/mL (56.33 mM)
Water <1 mg/mL (<1 mM)
Ethanol <1 mg/mL (<1 mM)
In vivo 30% PEG400/0.5% Tween80/5% propylene glycol 10 mg/mL
* <1 mg/ml means slightly soluble or insoluble.
* Please note that Selleck tests the solubility of all compounds in-house, and the actual solubility may differ slightly from published values. This is normal and is due to slight batch-to-batch variations.
Chemical Name 3-(2-(imidazo[1,2-b]pyridazin-3-yl)ethynyl)-4-methyl-N-(4-((4-methylpiperazin-1-yl)methyl)-3-(trifluoromethyl)phenyl)benzamide

Customer Product Validation (2)

Click to enlarge
Source Cancer Cell 2012 22(5), 656-667 . Ponatinib (AP24534) purchased from Selleck
Method Western blot
Cell Lines RCH-ACV cells
Concentrations 50 nM
Incubation Time 1-24 h
Results Treatment of these cells with a CSK inhibitor (BMS-599626) or a BTK inhibitor (PCI-32765) did not recapitulate the dasatinib/ponatinib phenotype.

Click to enlarge
Source Genome Biol, 2014, 15(8): 428 . Ponatinib (AP24534) purchased from Selleck
Method Cell Proliferation Assay
Cell Lines KatoIII cells
Concentrations 0-0.5 nM
Incubation Time
Results Each of the inhibitors demonstrated a statistically significant lower IC50 in FGFR2-amplified KatoIII cells compared to non-FGFR2-amplified AGS cells at all concentrations tested.

Product Use Citation (23)

Tech Support & FAQs

Answers to questions you may have can be found in the inhibitor handling instructions. Topics include how to prepare stock solutions, how to store inhibitors, and issues that need special attention for cell-based assays and animal experiments.

Tel: +1-832-582-8158 Ext:3

If you have any other enquiries, please leave a message.

* Indicates a Required Field

Related Bcr-Abl Products

  • PX-478 2HCl

    PX-478 2HCl is an orally active, and selective hypoxia-inducible factor-1α (HIF-1α) inhibitor. Phase 1.

  • Defactinib (VS-6063, PF-04554878)

    Defactinib (VS-6063, PF-04554878) is a selective, and orally active FAK inhibitor. Phase 2.

  • LY2874455

    LY2874455 is a pan-FGFR inhibitor with IC50 of 2.8 nM, 2.6 nM, 6.4 nM, and 6 nM for FGFR1, FGFR2, FGFR3, and FGFR4, respectively, and also inhibits VEGFR2 activity with IC50 of 7 nM. Phase 1.

  • Imatinib Mesylate (STI571)

    Imatinib Mesylate (STI571) is an orally bioavailability mesylate salt of Imatinib, which is a multi-target inhibitor of v-Abl, c-Kit and PDGFR with IC50 of 0.6 μM, 0.1 μM and 0.1 μM in cell-free or cell-based assays, respectively.

  • Nilotinib (AMN-107)

    Nilotinib (AMN-107) is a Bcr-Abl inhibitor with IC50 less than 30 nM in Murine myeloid progenitor cells.

    Features:A selective inhibitor of native and mutant Bcr-Abl.

  • Degrasyn (WP1130)

    Degrasyn (WP1130) is a selective deubiquitinase (DUB: USP5, UCH-L1, USP9x, USP14, and UCH37) inhibitor and also suppresses Bcr/Abl, also a JAK2 transducer (without affecting 20S proteasome) and activator of transcription (STAT).

    Features:WP1130 has an advantage over imatinib mesylate in that its activity is not inhibited by a variety of Abl kinase mutations, including T315I.

  • Bafetinib (INNO-406)

    Bafetinib (INNO-406) is a potent and selective dual Bcr-Abl/Lyn inhibitor with IC50 of 5.8 nM/19 nM in cell-free assays, does not inhibit the phosphorylation of the T315I mutant and is less potent to PDGFR and c-Kit. Phase 2.

    Features:Dual Bcr-Abl/Lyn inhibitor.

  • DCC-2036 (Rebastinib)

    DCC-2036 (Rebastinib) is a conformational control Bcr-Abl inhibitor for Abl1(WT) and Abl1(T315I) with IC50 of 0.8 nM and 4 nM, also inhibits SRC, LYN, FGR, HCK, KDR, FLT3, and Tie-2, and low activity to seen towards c-Kit. Phase 1.

    Features:A conformational control inhibitor of Abl1 and T315I Abl1.

  • GZD824 Dimesylate

    GZD824 Dimesylate is a novel orally bioavailable Bcr-Abl inhibitor for Bcr-Abl(WT) and Bcr-Abl(T315I) with IC50 of 0.34 nM and 0.68 nM, respectively.

  • PD173955

    PD173955 is a potent Bcr-Abl inhibitor with IC50 of 1-2 nM, also inhibiting Src activity with IC50 of 22 nM.
